Code Encryptor II
Location of the control module is the most important determining factor for range and
reliability of your Code Encryptor. Select a location that is as centrally located as pos-
sible. Keep in mind that your customer will want to control the operation of the garage
door from the driveway, and will also expect the use of the remote for alarm On/Off
in the area of entry and exit.
Since the Code Encryptor uses the communication bus wires from the keypad, you may
want to place the receiver in or near the garage to easily control the following
• Easy connection to the garage door push button
• Easy visual LED status mounting location
• Easy connection to the keypad wires for complete alarm control
Although you can wire at the panel, it may reduce labor by installing the Code
Encryptor II receiver at the point of entry. In most cases that is the garage which will
provide an easy installation for garage door Open/Close, status indicator and alarm
controls through the keypad. DO NOT MOUNT THE CONTROL MODULE IN
THE ALARM PANELS METAL ENCLOSURE.
Recommended
placement for
Code Encryptor
CODE
ENCRYPTOR
1
Garage
Basement
Bedroom
Attic
Point of Entry

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Honeywell Code Encryptor II and is the answer not in the manual?

Honeywell Code Encryptor II Specifications

Power IconPower
receiver power input12VDC
stand by power consumption15ma
Operating Environment IconOperating Environment
temperature range-5°F to 160°F
range150+ feet
frequency303Mhz
Remote Control IconRemote Control
battery12VDC Mini (Part #GP23A)
battery replacement frequencyonce a year
