LED Wiring
DO NOT CONNECT LED DIRECTLY TO GROUND!
The LED is a low voltage type and must run through the Code Encryptor II. If you
attempt to connect the purple wire directly to ground (-) the LED will burn and will
NOT operate again.
Go TO Channel 2 Outputs
8
Purple-
Connect to purple
of the wire harness.
Red (Aux+)

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Honeywell Code Encryptor II and is the answer not in the manual?

Honeywell Code Encryptor II Specifications

Power IconPower
receiver power input12VDC
stand by power consumption15ma
Operating Environment IconOperating Environment
temperature range-5°F to 160°F
range150+ feet
frequency303Mhz
Remote Control IconRemote Control
battery12VDC Mini (Part #GP23A)
battery replacement frequencyonce a year
