Optional Reversible Outputs
Channel 2 has two independent outputs that occur when button #2 is pressed. The
first output is a momentary relay contact closure which is intended for the use of
opening and closing a garage door. This is the primary output and can not be
changed or reconfigured. The second output is a (-) 500ma transistor output to
provide a zone bypass or illuminated entry/exit.
• If you are not using the relay for Channel 3 you may choose to swap the
(-) transistor output for the relay. In this instance you will then have two contact
closures every time Button # 2 is pressed. The standard momentary contact
closure and ALSO a Form C relay that will energize automatically for 3 minutes
every time the garage door is opened or closed.
To Swap the transistor and relay outputs.
Step 1) While watching the LED on the CE II receiver press and HOLD button 1 and
3 simultaneously on the remote control until the LED on the CE II receiver
illuminates. (approx. 5 seconds)
Step 2) To make channel 2 a relay press the program button on the CE II Receiver
TWICE, to make it a transistor output press ONCE (Default setting)
Step 3) Wait 10 seconds and the CE II will automatically reconfigure the outputs.
NOTE- Even if you swap outputs, the Panic button will still operate if
you press and HOLD button #3 for three seconds.
IMPORTANT
This feature will not work if you are using a
CADDX 8980E or a DSC 1550
