45
Port Default setting
The secondary controller static IP address: 192.168.1.51
To configure IP address
1. From the Home Page, click the arrow beside Configure Ethernet
Ports, and select ETH1 or ETH2.
2. Under Network Setting, configure the IP address of the Ethernet
port for the controller.
3. Under the Protocol Binding, select the protocol which you want to
bind to the port.
4. Click Save to complete the Ethernet port configuration.
5. Click Back to return to the Home Page.
TIP: If new IP settings are compiled and downloaded, the
controller will be disconnected from the configuring device.
Configuring controller start up
This function enables you to configure the controller status after the
power cycle.
For ControlEdge 900 controller, this feature is only applicable when
the mode switch is in REMOTE position.
Under Controller and Programming, select Configure Controller Start Up,
the Configure Controller Start Up page appears. There are four options
for controller start up:
n
Last operating mode, or Running after an abnormal stop
This option is the default setting for ControlEdge 2020 controller.
The controller will start in the operating mode that it was last in
prior to a power off, unless there was an abnormal stop caused by
a system error such as a watchdog timeout issue. It will then start
in Running mode.
l If the controller was in Running mode before power off, the
controller will warm start in Running. If the warm start fails, the
controller will go to Stopped mode.
l If the controller was stopped manually before power off, the
controller will start in Stopped mode.
l If the controller was stopped abnormally before power off, the
Chapter 4 - Software
