Identifying Orion Console components
Identify Experion Orion Console components within the shipping
crate.
Identification and location of Orion Console
components
The two position Experion Orion Console is shipped in a single crate,
and the three position console is shipped in two crates.
TIP: As the three position console is effectively the a pair of two
position consoles joined together and sharing a middle foot,
the crating and packing is identical for both consoles. The two
position console is designed to be installed on site using this
guide, but it is not recommended that the three position
console be installed by the customer without assistance from a
trained and certified installer. Therefore the instructions in this
guide are limited to those for the two position console.
Figure 3-1: Isometric view of the Experion Orion Console shipping crate
contents
12
Chapter 3 - Installing an Experion Orion Console
