Installation Guide and Operating Manual // Model FS20X™ Series
Honeywell 13
UBefore completing the installationU, check that the Detector is configured correctly for the specific
application. The FSX Detectors Factory Default Settings are:
Alarm Relay Outputs are Non-Latching and Normally De-Energized SW2-1 OFF SW2-7 OFF
Detector Range / Sensitivity is Medium SW2-2 OFF SW2-3 ON
Auxiliary Relay Verify Time is set to 5 Seconds SW2-4 ON SW2-5 ON
FACTORY USE ONLY SW2-6 OFF
Fault Relay Output is Normally Energized SW2-8 ON
Communication is set to FireBusII
SW3 is set to Position 4
Factory Use Only SW1-1 through SW1-3 OFF
Digital Communication Address is set to 127 SW1-4 through SW1-10 ON
If the application for the Detector requires different settings, refer to Section 3.2 for detailed descriptions.
U
Before applying 24 VDC power to the Detector, make sure
U:
1. Wire connections are correct (Section 2.3). Each wire must be stripped properly to the correct length,
loose wire strands must be removed and each wire must be securely and firmly screwed clockwise in
the connector.
2. If using conduit, ensure a proper conduit seal, (appropriate for the area classification), has been
installed and
Uall measures to prevent moisture ingress have been takenU.
3. Consult the manufacturer for dimensional information on the flameproof joint specifications.
4. The FSX Detector is securely mounted and has an unobstructed view of the area of coverage
(Section 2.1).
5. The Detector window is unobstructed and clean,
6. To ensure optimum performance, shield the detector face from intense bright light sources when first
energized.
The Detector is now ready for Power-Up.
UOn Power-Up, the Fault Relay will change status if the Factory
Default Setting is used (Section 3.2).
