Honeywell FSL100-IR3 User Manual

MAN0987_Iss 2_09/16
39
FSL100 Series Flame Detectors
Technical Handbook
CERTIFICATION
FSL100 General Specifications
Cone Of Vision
90°
Ingress Protection
IP65
Temperature, Operating, ATEX/IECEx/FM
-25 °C to +70 °C (-13 °F to +158 °F)
Temperature, Operating, Safe Areas
-40 °C to +70 °C (-40 °F to +158 °F)
Temperature, Storage
-40 °C to +70 °C (-40 °F to +158 °F)
Humidity Range
0 – 95 %RH, non-condensing
Automatic and Manual Self-Test
Automatic Sensor Test (Built in Self-Test) and manual self-test
Detector Body
GRP, Non-Incendive. UV resistant, Self-Extinguishing V-0 (UL-94).
Swivel Mounting
PA66 (UV Resist.), 316 SS (Fixings)
Dimensions (Body only)
125 x 80 x 57 mm (4.9 x 3.15 x 2.25 inch)
Weight
465 gram (1.05 lb)
745 g (1.67 lb) with optional mounting
Cable Gland
cores 0.5 to 1.5 mm
2
(20 to 16 AWG)
Pressure Compensating Element
The Pressure Compensating Element (PCE) helps prevent moisture
build up inside the detector housing caused by ambient fluctuation
Terminals
Suitable for cores 0.5 to 1.5 mm
2
(20 to 16 AWG), tightening torque
0.4 Nm (0.3 ft/lb)
EN54-10 Certificate
FSL100-IR3 Flame Detector: Class 1
FSL100-UV Flame Detector: Class 2
FSL100-UVIR Flame Detector: Class 2
ATEX Certificate
FSL100-IR3 Flame Detector: ATEX zone 2/22
FSL100-UV Flame Detector: ATEX zone 2/22
FSL100-UVIR Flame Detector: ATEX zone 2/22
FM3260 Approval
FSL100-IR3 Flame Detector
FSL100-UV Flame Detector
FSL100-UVIR Flame Detector
FM3611 Approval
FSL100-IR3 Flame Detector: Non-Incendive, Class 1,2 & 3 Div 2
FSL100-UV Flame Detector: Non-Incendive, Class 1,2 & 3 Div 2
FSL100-UVIR Flame Detector: Non-Incendive, Class 1,2 & 3 Div 2
RoHS
FLS100 Series is RoHS compliant
Table 3. FSL100 General Specifications
