Honeywell Genesis 7580G User Manual

11 - 4
Plug and Play Codes: USB USB Keyboard (PC) PAP124 2-3
USB Keyboard (Mac) PAP125 2-3
USB Japanese Keyboard (PC) TRMUSB134 2-3
USB HID PAP131 2-4
USB Serial TRMUSB130 2-4
CTS/RTS Emulation On USBCTS1 2-4
CTS/RTS Emulation Off* USBCTS0 2-4
ACK/NAK Mode On USBACK1 2-4
ACK/NAK Mode Off* USBACK0 2-4
Remote MasterMind for USB ReM Off REMIFC0 2-4
*ReM On REMIFC1 2-4
Plug and Play Codes Verifone Ruby Terminal PAPRBY 2-5
Gilbarco Terminal PAPGLB 2-5
Honeywell Bioptic Aux Port PAPBIO 2-5
Datalogic Magellan Aux Port PAPMAG 2-6
NCR Bioptic Aux Port PAPNCR 2-6
Wincor Nixdorf Terminal PAPWNX 2-6
Wincor Nixdorf Beetle PAPBTL 2-6
Program Keyboard
Country
*U.S.A. KBDCTY0 2-7
Albania KBDCTY35 2-7
Azeri (Cyrillic) KBDCTY81 2-7
Azeri (Latin) KBDCTY80 2-7
Belarus KBDCTY82 2-7
Belgium KBDCTY1 2-7
Bosnia KBDCTY33 2-7
Brazil KBDCTY16 2-7
Brazil (MS) KBDCTY59 2-7
Bulgaria (Cyrillic) KBDCTY52 2-8
Bulgaria (Latin) KBDCTY53 2-8
Canada (French legacy) KBDCTY54 2-8
Canada (French) KBDCTY18 2-8
Canada (Multilingual) KBDCTY55 2-8
Croatia KBDCTY32 2-8
Czech KBDCTY15 2-8
Czech (Programmers) KBDCTY40 2-8
Czech (QWERTY) KBDCTY39 2-8
Czech (QWERTZ) KBDCTY38 2-8
Denmark KBDCTY8 2-8
Dutch (Netherlands) KBDCTY11 2-9
Estonia KBDCTY41 2-9
Faroese KBDCTY83 2-9
Finland KBDCTY2 2-9
Selection
Setting
* Indicates default
Serial Command
# Indicates a numeric entry
Page

Honeywell Genesis 7580G Specifications

General

Type	Fixed bar code reader
Sensor type	-
Scanner type	1D/2D
Pitch reading angle	-70 - 70 °
Motion tolerance (cm/s)	200
Light levels (direct sunlight)	0 - 100000 lx
Standard interfaces	USB, RS-232, RS-485, Keyboard wedge
Product color	Black, Silver
Input voltage	5.5 V
Power consumption (standby)	0.5 W
Power consumption (typical)	2 W
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 95 %
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	80 mm
Width	83 mm
Height	150 mm
Weight	340 g
