Depth of Field Charts
Typical Performance
Guaranteed Performance
Focus Standard Range (SR)
Symbology Near Distance Far Distance
5 mil Code 39
in. 0.4 3.1
mm 10 79
7.5 mil Code 39
in. 0.2 4.7
mm 5 119
10mil Code 39
in. 0.0 6.5
mm 0.0 165
10 mil PDF417
in. 0.0 5.9
mm 0.0 150
13 mil UPC
in. 0.0 7.1
mm 0.0 180
20 mil Data Matrix
in. 0.1 7.5
mm 3 191
Resolution (1D Code 39) 4 mil (.102mm)
Resolution (2D Data Matrix) 7.5 mil (.19mm)
Focus Standard Range (SR)
Symbology Near Distance Far Distance
5 mil Code 39
in. 0.5 3.0
mm 13 76
7.5 mil Code 39
in. 0.4 4.4
mm 106 112
10mil Code 39
in.
0.0 6.2
mm
0.0 158
10 mil PDF417
in.
0.0 5.6
mm
0.0 142
13 mil UPC
in. 0.0 6.2
mm 0.0 158
20 mil Data Matrix
in.
0.3 7.2
mm 8 183
Resolution (1D Code 39) 4 mil (.102mm)
Resolution (2D Data Matrix) 7.5 mil (.19mm)
