Honeywell Genesis 7580G User Manual

11 - 11
*Data Formatter On,
Not Required,
Keep Prefix/Suffix
DFM_EN1 5-12
Data Format Required,
Keep Prefix/Suffix
DFM_EN2 5-12
Data Formatter On,
Not Required,
Drop Prefix/Suffix
DFM_EN3 5-12
Data Format Required,
Drop Prefix/Suffix
DFM_EN4 5-12
Data Format Non-Match Error Tone *Data Format Non-Match Error Tone On DFMDEC0 5-12
Data Format Non-Match Error Tone Off DFMDEC1 5-12
Primary/Alternate Data Formats Primary Data Format ALTFNM0 5-12
Data Format 1 ALTFNM1 5-13
Data Format 2 ALTFNM2 5-13
Data Format 3 ALTFNM3 5-13
Single Scan Data Format Change Single Scan-Primary
Data Format
VSAF_0 5-13
Single Scan-Data Format 1 VSAF_1 5-13
Single Scan-Data Format 2 VSAF_2 5-13
Single Scan-Data Format 3 VSAF_3 5-13
Symbologies
All Symbologies All Symbologies Off ALLENA0 6-1
All Symbologies On ALLENA1 6-1
Codabar Default All Codabar
Settings
CBRDFT 6-2
Off CBRENA0 6-2
*On CBRENA1 6-2
Codabar Start/Stop Char. *Don’t Transmit CBRSSX0 6-2
Transmit CBRSSX1 6-2
Codabar Check Char. *No Check Char. CBRCK20 6-2
Validate, But Don’t Transmit CBRCK21 6-3
Validate, and Transmit CBRCK22 6-3
Codabar Concatenation *Off CBRCCT0 6-3
On CBRCCT1 6-3
Require CBRCCT2 6-3
Codabar Message Length Minimum (2 - 60) *4 CBRMIN## 6-3
Maximum (2 - 60) *60 CBRMAX## 6-3
Code 39 Default All Code 39
Settings
C39DFT 6-4
Off C39ENA0 6-4
*On C39ENA1 6-4
Code 39 Start/Stop Char. *Don’t Transmit C39SSX0 6-4
Transmit C39SSX1 6-4
Selection
Setting
* Indicates default
Serial Command
# Indicates a numeric entry
Page

Honeywell Genesis 7580G Specifications

General

Type	Fixed bar code reader
Sensor type	-
Scanner type	1D/2D
Pitch reading angle	-70 - 70 °
Motion tolerance (cm/s)	200
Light levels (direct sunlight)	0 - 100000 lx
Standard interfaces	USB, RS-232, RS-485, Keyboard wedge
Product color	Black, Silver
Input voltage	5.5 V
Power consumption (standby)	0.5 W
Power consumption (typical)	2 W
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 95 %
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	80 mm
Width	83 mm
Height	150 mm
Weight	340 g
