Honeywell GF505 User Manual

ANN-BUS Devices Installation
Mounting/Installation
The GFANN-RLY relay module can be mounted inside the FACP main circuit board chassis or inside the ROME Series enclosure. Refer
to the GFANN-RLY Installation Document #53378 for instructions on chassis mounting or to the ROME Series Installation Document
#53530 for mounting in the separate backbox.
mounting holes
mounting hooks through
mounting slots
grounding wire
GFANN-RLY
ANN-MBRLY
mounting bracket
mounting holes
mounting holes
FACP Backbox Installation
using ANN-MBRLY mounting bracket
FACP Chassis Installation
mounting holes
mounting holes
GFANN-RLY on
ANN-MBRLY
mounting bracket
ROME Series Installation
using ANN-MBRLY mounting bracket
Figure 2.24 GFANN-RLY Mounting Options
GF505 & GF510 Manual — P/N 53164:B5 6/12/2018
41
