Honeywell HM750A1000 Quick Installation Guide

HM750A1000 Advanced Electrode Steam Humidifier
Home and Building Technologies
In the U.S.:
Honeywell
715 Peachtree Street NE
Atlanta, GA 30308
customer.honeywell.com
®U.S. Registered Trademark
© 2017 Honeywell International Inc.
33-00288EF—03 M.S. Rev. 09-17
Printed in United States
The product should not be disposed of with other household waste. Check for the nearest authorized collection centers or authorized recyclers. The correct disposal of
end-of-life equipment will help prevent potential negative consequences for the environment and human health.
CHECKOUT AND STARTUP
1. Make sure the voltage selector jumper on the main circuit board is correctly
configured to match the mains supply voltage (120 VAC or 240 VAC).
2.
If a disconnect switch is installed, turn it to the “
ON” position. The
humidifier will perform a short series of self-tests.
3.
Ensure the water supply valve is open.
4.
P
ress the power button on the humidifier.
5. Check the LEDs to determine which mode the humidifier is in (Fig. 10).
If there is a call for humidity, the “Filling” LED will illuminate. Once full, the
humidifier should start making steam between 5 and 20 minutes later, and
the “Humidifying” LED will illuminate. If there is not a call for humidity, the
“Idle” LED will illuminate.
TROUBLESHOOTING
Reference the troubleshooting label on the inside of the humidifier cover. For
all other inquiries, please consult the complete product guide available on
customer.honeywell.com or contact Honeywell Technical Support at
1-800-468-1502.
5 YEAR WARRANTY
Honeywell warrants this product to be free from defects in the workmanship or materials, under normal use and service, for a period of five (5) years from the date of purchase by the consumer.
If at any time during the warranty period the product is determined to be defective or malfunctions, Honeywell shall repair or replace it (at Honeywell’s option).
If the product is defective,
(i) return it, with a bill of sale or other dated proof of purchase, to the place from which you purchased it; or
(ii) call Honeywell Customer Care at 18004681502. Customer Care will make the determination whether the product should be returned to the following address:
Honeywell Return Goods, Dock 4 MN103860, 1985 Douglas Dr. N., Golden Valley, MN 55422,
or whether a replacement product can be sent to you.
This warranty does not cover removal or reinstallation costs. This warranty shall not apply if it is shown by Honeywell that the defect was caused by damage which occurred while the product
was in the possession of a consumer.
Honeywell’s sole responsibility shall be to repair or replace the product within the terms stated above. HONEYWELL SHALL NOT BE LIABLE FOR ANY LOSS OR DAMAGE OF ANY KIND,
INCLUDING ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES RESULTING, DIRECTLY OR INDIRECTLY, FROM ANY BREACH OF ANY WARRANTY, EXPRESS OR IMPLIED, OR ANY OTHER
FAILURE OF THIS PRODUCT. Some states do not allow the exclusion or limitation of incidental or consequential damages, so this limitation may not apply to you.
THIS WARRANTY IS THE ONLY EXPRESS WARRANTY HONEYWELL MAKES ON THIS PRODUCT. THE DURATION OF ANY IMPLIED WARRANTIES, INCLUDING THE WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, IS HEREBY LIMITED TO THE FIVEYEAR DURATION OF THIS WARRANTY.
Some states do not allow limitations on how long an implied warranty lasts, so the above limitation may not apply to you. This warranty gives you specific legal rights, and you may have other
rights which vary from state to state.
If you have any questions concerning this warranty, please write Honeywell Customer Care, 1985 Douglas Dr, Golden Valley, MN 55422 or call 18004681502.
IMPORTANT
To maintain warranty, Honeywell approved parts and cylinders must be used in the operation of the product.
SPECIFICATIONS
AHRI RECOMMENDED HUMIDITY
(in gallons per day)
Construction Type 8,000 ft
3
12,000 ft
3
16,000 ft
3
20,000 ft
3
24,000 ft
3
28,000 ft
3
32,000 ft
3
Tight 3.3 4.3 5.4 7.5 9.6 11.7 16
Average 7.6 9.6 11.8 16 20.3 24.4 33
Loose 11.7 14.9 18.1 24.5 30.8 37.1 50
Volts KW
Steam
Output Amps Phase
Circuit
Breaker Max
Current Dimensions Weight
Max Static
Pressure
120 1.5
3.85 lb/hr
(1.75 kg/hr)
11 GPD
12 A 1 15 A
10 x 7 x 18 in.
254 x 178 x 457 mm
10 lbs.
(15 lbs. when full)
4.5 kg.
(7.0 kg. when full)
2 in. w.c. positive
backpressure
3 in. w.c. negative
backpressure
240 3.0
7.7 lb/hr
(3.5 kg/hr)
22 GPD
