WIRING DIAGRAM
30 www.honeywellgenerators.com HW5600C Portable Electrical Generator Owner’s Manual
WIRING DIAGRAM
G G
W W
X X
G
G
G
Y
W
X
ALTERNATOR
CONTROL PANEL
ENGINE
OIL ALERT SENDER SPARK PLUG OIL SHUTDOWN SWITCH IGNITION COIL
ENGINE BLOCK
Y
Y
Bl
Y
Bl
Bl
ENGINE
CONTROL
SWITCH
Bl
Bu
EIG
GROUND TERMINAL
DUPLEX 5-20R
Y/G
SINGLE POLE
THERMAL
AC BREAKER
120V 20A
FIELD
WINDING
MAIN
WINDING
EXCITER
WINDING
AVR
WR GWBuBu
ALTERNATOR
Bl - Black Bu - Blue Br - Brown G - Green G/W - Green / White R - Red Y - Yellow Y/G - Yellow / Green W - White
SINGLE POLE
THERMAL
AC BREAKER
120V 20A
NOTE: Alternator is mechanically connected to the engine block providing ground connection between the engine block and the alternator frame.
ON/OFF SWITCH PANEL
DUPLEX 5-20R
MAIN
WINDING
Br
WR
Bu
WR
Bu
FUEL
CUTOUT
WINDING
5A FUSE
G/W
G/W
TWIST-LOCK
L14-30R
Y/G
Br Br
DUAL POLE
MAGNETIC
AC BREAKER
240V 25A
120 VAC 120 VAC
OFF ON
Bu Bl&YG/W Y/G
LEFT* RIGHT*
*When looking at the control panel front
120V DC
Hour Meter
Y
Bu
G/W
Rear Bearing
Carrier Ground
Y/G
W W
Y Y
Generator
Frame
Rear Bearing
Carrier Leg
Y/G
FUEL CUTOUT SOLENOID
TOP
BOTTOM
