Honeywell HW5600C - Specifications and Wiring Diagram

HW5600C Portable Electrical Generator Owner’s Manual www.honeywellgenerators.com 29
SPECIFICATIONS AND WIRING DIAGRAM
GENERATOR
Dimensions
*
* Measurements given reflect dimensions with accessory kit installed.
Length [in / mm]
29.4 / 746
Width [in / mm]
28.7 / 729
Height [in / mm]
26.6 / 675
Dry Weight [lb / kg]
193 / 87.5
AC Output
Rated Power [watts]
5600
Maximum Power [watts]
7750
Frequency [hertz]
60
Voltage [volts]
120 / 240
Operating Temperature
Maximum [F / C]
104
q/ 40q
Minimum [F / C]
14
q / -10q
ENGINE
Speed [rpm]
3600
Typ e
OHV 4-Cycle
Displacement [cc]
389
Valve Lash [in /mm]
IN: 0.005±0.001 / 0.125±0.025
EX: 0.007±0.001 / 0.175±0.025
Fuel
87 or higher unleaded
Fuel Tank Capacity [gal / L]
6.3 / 24
Engine Oil
SAE 10W-30
†
† See page 18 for other engine oil types outside general temperature use.
Engine Oil Capacity [qt / L]
1.2 / 1.1
Spark Plug
100842A
‡
‡ See page 23 for other recommended spark plug replacements.
Spark Plug Gap [in / mm]
0.028-0.031 /
0.70-0.80
Air Filter
100833A
TABLE 7. HW5600C Portable Electrical Generator Specifications
