ECS Series Emergency Communication System Installation Manual 151455
3-2
be reduced by running the wire through ferrite shield beads or by wrapping it around a ferrite toroid.
Figure 3-1 Wire Routing Example
Note: All circuits are power limited except the battery and AC cabling. Maintain 1/4 inch spacing between high
Telco Wiring
NACs
SBUS
Devices
SLC Devices
Relays
IFP-100ECS
SBUS
Devices
Flexputs / NACs
VBUS
VBUS
AC
AC
Relays
SLC
Devices
IFP-1000ECS
