ECS Series Emergency Communication System Installation Manual 151455
4-2
Figure 4-2 Front View of ECS-VCM
4.2.2 Connecting the ECS-VCM to the SBUS
Refer to Figure 4-3 to properly connect the ECS-VCM to the FACPs SBUS.
Figure 4-3 SBUS Connections
See Section 4.12 to set SBUS addressing.
FACP
ECS-VCM
Supervised
Power Limited
