3.4.4 Surface Mounting the IFP-300ECS Cabinet
The Cabinets can be mounted on the wall surface by using the mounting holes in the back of the
cabinet (see Figure 3-6). For more information, refer to Installation manuals for IFP-300ECS (PN
LS10145-001SK-E).
Cabinet backbox dimensions are 26.5"H x 20"W x 4.1"D
Figure 3-7 IFP-300ECS Cabinet Mounting Holes
26.5"
Bottom Mounting
Holes
Key Shaped Holes
20"
