Mounting TCC to combination controlCG
▷ Use the adapter plate supplied to mount the
TC1C to combination controlCG.
▷ Connect the TC to the inlet pressure connec-
tionp
u
and the interspace pressure connection
p
z
of the inlet valve. Ensure that connections p
u
and p
z
on the CG are not reversed.
p
z
p
z
p
u
p
u
6
87 9
10
max. 250 Ncm
Mounting TC
▷ Connect the TC to the inlet pressure connection
p
u
and the interspace pressure connection p
z
of
the inlet valve.
▷ Use the adapter plate supplied for installation.
TC 2..R: Rp ¼
TC 2..N: ¼ NPT
Rp ¼ (¼ NPT)
p
u
p
z
p
z
▷ We recommend using Ermeto screw couplings
to attach the adapter plate to the gas solenoid
valve. It may be necessary to compensate the
distance to the valve housing.
p
u
▷ Only use approved sealing material to seal the
pipe connections.
250 Ncm
p
u
p
z
6 7
8
10 11
9 Connect the interspace pressure connectionp
z
on the adapter plate to the space between the
valves using a 12x1.5 or 8x1 pipe.
p
z
p
z
▷ Ensure that connections p
u
and p
z
on the TC
and adapter plate are not reversed.
250 Ncm
p
u
p
z
6 7 8
10 11
Mounting TC
▷ Connect the TC to the inlet pressure connection
p
u
, the interspace pressure connection p
z
and
the outlet pressure connection p
d
of the inlet
valve. Ensure that connections p
u
, p
z
and p
d
on
the TC are not reversed.
▷ TC 3..R: Rp 1/4, TC 3..N: 1/4 NPT
p
z
p
d
p
z
p
u
p
u
p
d
p
z
▷ Use a 12x1.5 or 8x1 pipe for the pipe con-
nections.
p
z
p
d
p
z
p
u
p
u
p
d
p
z
6 Mount TC3.
▷ Only use approved sealing material to seal the
pipe connections.
7 Seal the unused connection p
z
on the TC using
the sealing plug supplied.
