Honeywell L5200 Series User Manual

– 47 –
USER FUNCTIONS
Automation
Rules
Up to 40 rules can be programmed. Rules 1 through 20 are used for Triggers, Z-Wave Scenes and Follow-Me
Messages. Rules 21 through 40 are used for Z-Wave Scenes and for E-mail notification and are only accessible
through TotalConnect Service. Check with your Installer to see which options are available to you.
The following options are programmed in this section:
Programming Field
A
ction
Rule 1 - 20:
Select Rule 1 -20 Note: Rules 21-40 are only accessible through TotalConnect Service.
Name: Name the device
Type: Select the output type
Action: Select the action required for the device
Start Zone Type: Select Zone Type to start event
Stop Zone Type: Select Zone Type to stop event
Start System Operation: Select System Operation to start event
Stop System Operation: Select System Operation to stop event
Zone Number Operation: Select Zone Number to trigger event upon fault, trouble or alarm as selected.
Programming Rules
5200-100-001-V0
Video
Notices
Traffic
Security
News
5-Day Forecast
2
68
35 1:
F
PM
October 1, 2013
Feels Like 71
Mostly Sunny
F
Automation
Ready To Arm
1. With the system in the disarmed state, select the “Automation”
icon from the Home Screen. The system displays the first
page of the Automation screen. Select the “” icon to
advance to the second page of the Automation screen.
5200-100-053-V0
Garage door setup
Tools
Rules
Schedules
Scenes
Ready To Arm
2. Select the “Rules” button. The system displays the Rules
screen.
5200-200FR-194-V0
Modifier Effacer
Prêt à armer
Règle 5
Nouvelle
Règle 1
Renvois d’appels
Règle 3
Nouvelle
Règle 6
Nouvelle
Règle 2
Nouvelle
Règle 4
Nouvelle
3. Select a “Rules” key followed by the Edit button.
Note: Rules 21-40 are only accessible through TotalConnect
Service.
