Dimension Series MORLEY-IAS
User Manual Document No.996-148-000-5, Revision: 5 Page 15
4.2.4 Disablement Conditions
If zones, input devices, output devices or other disablement conditions have been programmed, the
DISABLEMENT LED is illuminated along with other appropriate system condition LED Indicators.
To view more detailed information regarding the disablement conditions use the navigation keys as
follows.
Press the ÍÏÐÎ keys to select the DISABLED option, then press the
9 key and the display shows
further information on the faults. For example:
TOTAL PANEL DISABLED :3 :Panel Events
TOTAL ZONES DISABLED :3 :Zone Details
This display indicates that there are three zones in either a full or partial disablement condition and
that three panel related disablements have been configured. To view these, press the Î key to view
the panel related disablement and press the Ð key to view the zones in disablement.
4.2.4.1 Panel Disablements
DISABLED 01/03 12:15
DISABLE ALL SOUNDERS :back R:more
The above example shows there are three panel related disablements and the first disablement is
shown. This was a disablement of all sounders / bells configured at 12:15PM.
If there is more than one disablement indicated, use the Ï and Ð keys to view these (Note: The ‘R:
more’ option is not shown if there is only one event, the ‘’ and keys are shown for the first and last
entries in the list). Press the Í key to return to the main display.
4.2.4.2 Zone Disablements
When selected, the display shows the first zone with a disablement condition. For example:
DISABLED ZONE 1 01/03 R: More Zones
<Zone-Location-Text> ZONE FULLY DISABLED
The display shows the Zone number and Zone Location Text (20 character description), the
disablement number and total number of zones in a disablement condition (01/03) and whether the
zone is fully disabled. If the zone is only partially disabled, the display is as follows:
DISABLED ZONE 1 02/03 R: More Zones
<Zone-Location-Text> :Device Details
To view other zones in a disablement condition (or to return to the main display), press the Ï and Ð
keys.
EN54
9
EN54-2 9.5
Disablement of
each addressable
point.
To view the devices (points) in a zone with only partial disablement
condition, press the Î key. The display then shows the first point in
disablement in the selected zone. For example:
