4
INTRODUCTION
Scanner Components
Figure 1. Scanner Components
ITEM NO. DESCRIPTION
1 Red Output Window, Laser Aperture (See page 36)
2 Mode Select Button (See page 13)
3 Beeper (See page 15)
4 Blue LED, Single-Line Mode / Menu Reading (See page 15)
5 White LED (See page 15)
6
Blue LED,
All Scan Lines On / Omnidirectional Reading (See page 15)
7 Amber LED, CodeGate (See page 15)
8 CodeGate Button (See page 14)
9 Pin Hole for Cable Release (See page 6)
10 10-Pin RJ45, Female Socket (See page 32)

Other manuals for Honeywell MS3780 Fusion

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Honeywell MS3780 Fusion and is the answer not in the manual?

Honeywell MS3780 Fusion Specifications

General IconGeneral
Scan speed1333 sec/page
Wavelength650 nm
Decoding standards1D, GS1
Dimensions (WxDxH)189 x 65 x 73 mm
Standard interfacesKeyboard wedge
Input voltage5 V
CertificationFCC Part 15, ICES-003, EN55022 Class B
Product colorBlack
Storage temperature (T-T)-40 - 60 °C
Operating temperature (T-T)-20 - 40 °C
Operating relative humidity (H-H)5 - 95 %
Weight and Dimensions IconWeight and Dimensions
Weight195 g
