Reporting Formats Ademco Contact ID
• 3 = New Restore
• XYZ = Event code. Refer to Table 5.2 for event code definitions.
• GG = Group number. Zeroes, or the value defined in VeriFire Tools programming. (Refer to page 24.)
• CCC = Device or Zone number.
• If the report concerns a specific point or zone, this field contains the UDACT-2 address of the device or zone. (See the
description of the “Point Address at Central Station” field on page 27).
• If the report is general (i.e., not a report concerning a specific point or zone) this field will display zeroes, or the value defined in
VeriFire Tools programming. (Refer to page 24.)
Table 5.2 Ademco Contact ID Reporting Format
NOTE: For general reports (alarm, trouble and supervisory), the GG and CCC fields are transmitted as 00 and 000 unless values are
entered in the VeriFire Tools “Group” and “General Points Device Number” fields. (Refer to page 24.)
Data Description Event Code
General Alarm 110*
Zone/point Alarm 110*
General Supervisory 200
Zone/point Supervisory 200
General Fault 300
AC Fault 301
Zone/point Fault 380
Low Battery 302
Telco Primary Line Fault 351
Telco Secondary Line Fault 352
NAC Fault 321
Communication Trouble Primary # 354
Communication Trouble Secondary # 354
485 Communication Trouble 300
System Off Normal 308
Reserved 000
System 24 Hour Test 602
System 24 Hour Test with Active Event 608
Manual Test 601
Security Alarm 130
Future Use 310
Future Use 394
Future Use 393
Zone/point defined as fire alarm 110
Disable zone/point report 000
Zone/point defined as supervisory 200
Zone/point defined as pull station 115
Zone/point defined as heat detector 114
Zone/point defined as water flow 113
Zone/point defined as duct detector 116
Zone/point defined as pre-alarm 118
Zone/point defined as smoke 111
Zone/point defined as burglary 130
Zone/point defined as 24 hour non-burglary 150
Zone/point defined as high temperature 158
Zone/point defined as low temperature 159
Zone/point defined as low water pressure 201
Zone/point defined as low water level 204
Zone/point defined as pump failure 206
Zone/point defined as photo-co detector 162
* Factory default, reprogrammable.
Note: Zero event entries prevent the transmission of the report to the Central Station.
