29 UDACT-2 — Instruction Manual P/N 54089:B3 10/29/2019
Section 5: Reporting Formats
The formats sent by the UDACT-2 to the Central Station are set out in this section. Event codes are defined for each protocol.
Use Ademco Contact ID for specific zone or point identification.
Pulsed formats typically require 15 to 20 seconds for message transmission.
Refer to Section 6.1, “Compatible UL Listed Receivers”, on page 33 for a list of compatible receivers.
5.1 “4 + 2” Standard
Standard “4 + 2” reporting consists of the following format:
XXXX EE
• XXXX = 4-digit Customer Account Code.
• EE = Event Code Refer to Table 5.1 for code definitions.
The table below shows the data reporting format for the “4+2 Standard” pulsed format.
Table 5.1 4+2 Standard Data Reporting Format
5.2 Ademco Contact ID
Ademco Contact ID reporting consists of the following format:
SSSS 18 QXYZ GG CCC
• SSSS = 4-digit Customer Account Code.
• 18 = Identifies transmission as Ademco contact ID to the receiver at the Central Station.
• Q = Event Qualifier
• 1 = New Event
Data Description
Data Reporting Format
4-digit Customer
Account Code
Event
Code
General Alarm xxxx 11
Zone/point alarm code xxxx 00
General Supervisory xxxx 81
Zone/point supervisory code xxxx 00
General Fault xxxx F1
AC Fault xxxx F6
Zone/point fault code xxxx 00
Low Battery fault xxxx F8
Telco Primary Line Fault xxxx FA
Telco Secondary Line Fault xxxx FB
NAC Fault xxxx FC
Communication Trouble Primary # xxxx FD
Communication Trouble Secondary # xxxx FE
485 Communication Trouble xxxx FE
System Off Normal xxxx FF
Reserved xxxx 00
Reserved xxxx 00
Reserved xxxx 00
Reserved xxxx 00
Security alarm xxxx 11
General Alarm restore xxxx E1
Zone/point alarm restore xxxx 00
General Supervisory restore xxxx E2
Zone/point supervisory restore xxxx 00
General Fault Restore xxxx E3
AC Fault Restore xxxx E6
Zone/point fault restore xxxx 00
Low Battery Fault Restore xxxx E8
Telco Primary Line Fault Restore xxxx EA
Telco Secondary Line Fault Restore xxxx EB
NAC Fault Restore xxxx EC
Communication Trouble Primary Number Restore xxxx ED
Communication Trouble Secondary Number Restore xxxx EE
485 Communication trouble restore xxxx EE
System Off Normal Restore xxxx EF
Reserved xxxx 00
System 24 Hour Test xxxx 99
System 24 Hour Test with Active Event xxxx 91
Manual Test xxxx 92
Security alarm Restore xxxx E1
Note: Zero event entries prevent the transmission of the report to the Central Station.
