16
Controlling PTZ Cameras with the PTZ Control Panel
The PTZ control panel in the live view window provides a series of PTZ control buttons, as shown in the following figure:
Controlling PTZ Cameras with the Live View Menu
Playback
Playback of Recorded Video
To play back files from a general search:
1. Click Menuļ Video Search to enter the Video Search menu.
2. Select the General tab, then set the search parameters by selecting cameras to search, a video/file type, and the
start and end times.
Control Action
Call Preset Call a PTZ preset.
Call Patrol Call a PTZ patrol.
Call Pattern Call a PTZ pattern.
Preset Settings Enter the PTZ preset configuration menu.
Patrol Settings Enter the PTZ patrol configuration menu.
Pattern Settings Enter the PTZ pattern configuration menu.
PTZ Menu Enter the PTZ menu.
PTZ Settings Enter the PTZ Settings menu.
3
2
1
4
56789
# Control Action
1 Directional
Pad/Auto-scan
Buttons
Controls the movements and directions of the
PTZ. The center button is also used to start
auto-scan of PTZ.
2Zoom Used to zoom in and out with the PTZ.
3Focus Used to adjust the focus of the PTZ.
4 Iris Used to open or close the iris of the PTZ.
5 Speed Adjusts the movement speed of the PTZ.
6Light Turns the PTZ light (if applicable) on and off.
7Wiper Turns the PTZ wiper (if applicable) on and off.
8Zoom In Instantly zooms PTZ in.
9Center Centers PTZ. Camera: Select a PTZ camera.
