8 PRO-2200 Remote Enclosure—PRO22ENC3Installation Guide
PW-5000 Remote Enclosure
Description
The PRO-2200 Remote Enclosure allows for a variety of system configurations. It can be
used in combination with the PRO22ENC1, for example to place modules closer to the
doors they control. Or it can be used alone to house modules for a smaller system.
This enclosure can mount two full size PRO-2200 panels (PRO22IC,PRO22IN,
PRO22OUT, PRO22R2) OR one full size panel, one PRO22R1 single reader panel and one
PRO22MX8 multiplexer panel.
The 2 amp power supply provides power for the modules. The battery is a 4.0 amp hour
battery capable of providing 2.5 to 4 hours backup, depending on configuration.
Dimensions
Height: 14" (0,356 m)
Width: 16" (0,406 m)
Depth: 4" (0,102 m)
Metal thickness: .05" (0,00127 m)
Color: Autumn White
Installation holes: Three hangers in a triangular pattern are provided for mounting the
cabinet. The top two are located .29" from the top and spaced 13.75 inches apart. The
lower hanger is located .930" from the bottom and 7.85" from each edge. See Enclosure
Drawing.
Conduit Knockout
½" (0,00127 m) 2" (0,0508 m)
Top Side: 3 1
Bottom Side: 3 1
Right Side: 3 1
Left Side: 3 0
Rear Side: 4 0
