PRO-2200 Remote Enclosure—PRO22ENC3 9Installation Guide
Power Supply
DO NOT USE POWER SUPPLY TO POWER LOCKS
- 12 VDC 2 amp continuous power limited output with backup battery charging and
battery supervision.
- A 16.5 VAC 20 VA wall transformer is provided.
- Requires 115 VAC/60 hz.
- Maximum battery charge current .5 amp.
- AC on LED.
- AC Fail supervision.
- Low Battery Supervision (form “C” contacts).
- Short circuit and thermal overload protection.
Note:
All power connection should be made with 18 gauge or larger wiring.
LED Diagnostics
AC LED DC LED
ON ON Normal operating conditions
OFF ON Loss of AC, standby battery supplying power
ON OFF No DC output
OFF OFF Loss of AC, Discharged or no Standby battery. No DC output.
Backup Power Supply
• Automatic Switch over to standby battery when AC fails (zero voltage drop).
• 4.0 amp hour sealed rechargeable battery (BAT-3).
• Backup time: 1 hr. at maximum 2 amp current draw (longer for configurations with lower
current draw).
Cables Supplied
• Power On Light assembly.
• Tamper Switch assembly - Use of Tamper Switch is required by UL294.
Maintenance
• Replace the 12V 4 amp hour battery every 2 to 2.5 years.
• Oil the hinges on the door every 12 months.
Operating Parameters
• Temperature: 35° F to 110° F (2° C to 43° C).
• Operating Humidity: Up to 85% non-condensing.
