PW-7000 Output Module (PW7K1OUT) Installation Guide, Document 800-25675V1 3
Set Up
Table 1: PW-7000 Output Module Jumper Setting
Table 2: PW-7000 Output Module DIP Switch Settings
Jumper Setting Default Selected
J1
OFF * Port 1 RS-485 EOL terminator is not active
ON Port 1 RS-485 EOL terminator is active
S8 S7 S6 S5 S4 S3 S2 S1 Selection
OFF OFF OFF OFF OFF ADDRESS 0
OFF OFF OFF OFF ON ADDRESS 1*
OFF OFF OFF ON OFF ADDRESS 2
OFF OFF OFF ON ON ADDRESS 3
OFF OFF ON OFF OFF ADDRESS 4
OFF OFF ON OFF ON ADDRESS 5
OFF OFF ON ON OFF ADDRESS 6
OFF OFF ON ON ON ADDRESS 7
OFF ON OFF OFF OFF ADDRESS 8
OFF ON OFF OFF ON ADDRESS 9
OFF ON OFF ON OFF ADDRESS 10
OFF ON OFF ON ON ADDRESS 11
OFF ON ON OFF OFF ADDRESS 12
OFF ON ON OFF ON ADDRESS 13
OFF ON ON ON OFF ADDRESS 14
OFF ON ON ON ON ADDRESS 15
ON OFF OFF OFF OFF ADDRESS 16
ON OFF OFF OFF ON ADDRESS 17
ON OFF OFF ON OFF ADDRESS 18
ON OFF OFF ON ON ADDRESS 19
ON OFF ON OFF OFF ADDRESS 20
ON OFF ON OFF ON ADDRESS 21
ON OFF ON ON OFF ADDRESS 22
ON OFF ON ON ON ADDRESS 23
ON ON OFF OFF OFF ADDRESS 24
ON ON OFF OFF ON ADDRESS 25
ON ON OFF ON OFF ADDRESS 26
ON ON OFF ON ON ADDRESS 27
ON ON ON OFF OFF ADDRESS 28
ON ON ON OFF ON ADDRESS 29
ON ON ON ON OFF ADDRESS 30
ON ON ON ON ON ADDRESS 31
OFF OFF Reserved
