RTH3100C
11
1. Haga coincidir cada cable
marcado con el terminal que
tenga la misma letra.
2. Use un destornillador para
aflojar los terminales del
tornillo, inserte los cables y,
luego, ajuste los tornillos.
3. Introduzca el excedente de
cable en la abertura de la
pared.
¿Las etiquetas no
coinciden?
Si las etiquetas no coinciden
con las letras del termostato,
vealasiguientepágina.
Conecte los cables (instalación típica)
