11 69-1730
Step 6. Mount New Wallplate to Wall
1. Separate the wallplate from the thermostat as
shown.
THERMOSTAT
WIRE HOLE
M22267
WALLPLATE
69-1730.fm Page 11 Tuesday, July 13, 2004 12:45 PM
