69-1730 12
Step 6. Mount New Wallplate to Wall (Cont)
2. Pass the labeled wires through the wire hole on the
wallplate.
M22279
WIRE HOLE
WALL OPENING
WALLPLATE
LABELED WIRES
69-1730.fm Page 12 Tuesday, July 13, 2004 12:45 PM
