69-2206ES—05 2
Remove old thermostat but leave wallplate with
wires attached.
2
Remove Old Thermostat
M28099
Is there a sealed tube containing
mercury? If so, see back cover
for proper disposal instructions.
Leave wallplate
in place
Old thermostat
Cover

Table of Contents

Other manuals for Honeywell RTH7600 Series

Preview: Quick Start Guide
Quick Start Guide2 pages
Preview: Quick Installation Guide
Quick Installation Guide60 pages

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Honeywell RTH7600 Series and is the answer not in the manual?

Honeywell RTH7600 Series Specifications

General IconGeneral
Programmability7-day programmable
Temperature Range40°F to 90°F (4°C to 32°C)
Accuracy+/- 1°F
Hold FunctionYes
Filter Change AlertYes
Power SourceBattery and/or Hardwired
CompatibilityGas, oil, electric, heat pump systems
Temperature ControlPrecise temperature control of +/-1°F
Stages2 Heat/2 Cool
Display TypeTouchscreen
Weight6.4 oz (181 g)
