S9360A, S9361A, S9380A, S9381A INTEGRATED BOILER CONTROLLERS
5 66-1203—05
Fig. 2. Recommended slot/hole pattern in appliance (in mm).
Fig. 3. Align module with slots in manufacturer’s control box.
100
M24198
16
16
55
4
99.5
4
WATER
HEATER
CONTRO
L
BOX
M24229
