Sensepoint XCD Transmitter
Use 3-wire, 4-20mA, gas detector transmitter for use with remotely mounted flammable gas detectors.
Input Voltage Range:
Max Power Consumption:
Current output
≥
0.0<1.0 mA
4.0 mA to 20.0 mA
2.0 mA or 4.0 mA
22.0 mA
Terminals
Relays
Communication
16 to 32Vdc (24Vdc nominal)
Max 5 Watts. at 24Vdc (see section 2 regarding maximum in
rush current)
4-20mA (Source or Sink)
Fault (refer to table 5 section 12.3 for further details).
Normal gas measurement
Inhibit (during confi
guration/user settings)
Maximum over range
15 x screw terminals suitable for wire diameter 0.5mm
2
to
2.5mm
2
(20AWG to 13AWG).
3 x 5A@250VAC. Selectable normally open or normally closed
(switch) and energized/de-energized (programmable).
RS485, Modbus RTU(Pending)
Construction
Material Epoxy painted aluminum alloy or 316 Stainless Steel
Weight Aluminum alloy: 1.7kg, 316 Stainless Steel: 3.7kg
Mounting Pole or wall mounting
Cable Entries
Sensor Entries
2 x 3/4"NPT (for cCSAus/UL Approval)
3/4"NPT (for cCSAus/UL Approval)
Detectable Gases & Performance (See notes below)
International
North America
CE
EN50270:2006 EN6100-6-4:2007
Performance C22.2-152, ISA 121301
Environmental
IP Rating IP66 in accordance with EN60529:1992, NEMA 4X (Tested by third party laboratory)
Operating
Temperature
-40ºC to +65ºC/ -40ºF to +149ºF, (IR: -20ºC to +50ºC/ -4ºF to +122ºF).
Note: The detector display may become illegible at temperatures below -20°C, but the detector continues its gas monitoring
function. The display is not damaged and recovers when the temperature rises back above -20 °C.
Operating Pressure
90-110kPa
Storage Conditions
-25°C to +65°C (-13°F to +149°F)
Gas Selectable Full
Scale Range
Default
Range
Steps Selectable
Cal Gas
Range
Default Cal
Point
Response
Time (T60)
Secs
Response
Time (T90)
Secs
Accuracy Operating Temperature
Min Max
Default Alarm Points
A1 A2
705 Standard Temperature Sensor
25 to 95% of
selected full
scale range
Flammable 1 to 8*
20 to 100%LEL 100%LEL 10%LEL 50%LEL <25 <+/- 1.5%LEL -55°C / -67°F 80°C / 176°F 20%LEL ▲ 40%LEL ▲
705 High Temperature Sensor
Flammable 1 to 8*
20 to 100%LEL 100%LEL 10%LEL 50%LEL <6 <10 <+/- 1.5%LEL -55°C / -67°F 150°C / 302°F 20%LEL ▲ 40%LEL ▲
▲ - Rising Alarm ▼ - Falling Alarm
*Contact Honeywell Analytics for availability
Flammable 1 to 8* 20%LEL 20%LEL n/a 10%LEL <25 <+/- 1.5%LEL -55°C / -67°F 150°C / 302°F 10%LEL ▲ 15%LEL ▲
Hydrogen
Methane
Butane
Propane
Pentane
Ethylene
705
*6
*6
*3
*3
*2
*4
705HT
*6
*7
*4
*5
*4
*6
705 Sensor
Calibration gas
50% Hydrogen/air
50% Methane/air
50% Butane/air
50% Propane/air
50% Pentane/air
50% Ethylene/air
Adjust to
50%
50%
50%
50%
50%
50%
705HT Sensor
Calibration gas
50% Hydrogen/air
50% Methane/air
50% Butane/air
50% Propane/air
50% Pentane/air
50% Ethylene/air
Adjust to
50%
50%
50%
50%
50%
50%
NOTES
Performance figures are taken at 20~25℃;
1. measured using a sample humidity of 50%RH, applicable between 10 and 90% of full scale,
2. measured using test units calibrated at 50% of full scale,
3. measured at 1000cc/min for Methane CAT, 500cc/min for Methane IR with calibration cup (S3KCAL).
Response time (T90) may increase when operating in lower or higher temperature conditions or when gas is introduced with the Weather
Protection accessory (SPXCDWP) fitted. Should it be exposed to other HC then non linear response is expected. For linearised operation
other than Methane contact HA for alternate parts. This calibration enables 100% functional test prior to dispatch.
This calibration does not remove need for calibration & test as part of commissioning at site. For gases other than Methane the unit has
to be calibrated at site using target gas.Data represents typical values, and system conditioning may be required to achieve stated result.
Contact HA for details.
* Extended operating temperature range of -40°C to +65°C (-40°F to +149°F) for all sensor , with an accuracy of +/- 30% of applied gas
from -20°C to -40°C (-4°F to -40°F) and +55°C to +65°C (+131°F to +149°F). Long term operation at this range may cause decline in
sensor performance.
Contact Honeywell Analytics for any additional data or details.
Operating Humidity
Continuous 20-90%RH (non condensing), Intermittent 10-99%RH (non condensing)
IEC Ex II 2 GD Ex d IIC Gb T6(Ta -40ºC to +65ºC) Ex tb IIIC T85ºC Db IP66
cCSAus Class I, Division 1, Groups B, C & D
Latin America Inmetro, Ex d IIC T6 Gb; Ex tb IIIC T85°C Db IP66, -40°C < Ta < +65°C;
Ex d IIC T5 Gb, Ex tb IIIC T 100°C Db, IP66 -40°C < Ta < +75°C
Note: Performance approval is based on the standard 705 sensor calibrated to Methane
