Sensepoint XCD RFD Technical Manual SPXCDHMRFENU Issue 1
51
17 Installation Drawing
17.1 Mechanical Installation Drawing
NTS
SA
07-Dec-09
Sensepoint XCD
RFD Installation
Drawing
3001G0453
A
07/DEC/09
New
Drawing
J.Y.JIN
03/MAR/10
B
Text
Modify
J.Y.JIN
C
07/APR/10
Add Sheet
J.Y.JINJ.Y.JIN
04/May/10
D
Table
Change
E
07/Jun/10
Add Sheet
J.Y.JIN
3001G0453
I. SPECIFICATION
1. SIZE: 164 X 217 X 99
2. MATERIAL
A. TRANSMITTER: LM25 / 316SS
B. MOUTING BRACKET: 316SS
3. WEIGHT: 2kg / 4.5kg
A. TRANSMITTER(LM25): 1.8kg
B. TRANSMITTER(316SS): 4.3kg
C. MOUNING BRACKET: 0.2kg
II. HAZARDOUS CERTIFICATION
1. ATEX
II 2 GD
Ex d IIC Gb T6(Ta -40
℃ to +65 ℃)
Ex tb IIIC T85
℃ Db IP66
Baseefa08ATEX0222
2. KTL
Ex d IIC T6, 16~32Volts DC, Pmax=5W
Tamb. -40
℃ to +65 ℃
3. GB, PA
III. ITEM LIST
1. XCD RFD TRANSMITTER
2. PIPE MOUNTING BRACKET
M8 Bolt
164
80
1
0
6
80
1
3
9
99
1
4 - M8 Bolt
130
9
9
99
72
80
17,00
1
0
1
3
1
0
6
4 -
8.50 HOLE
2
To Next Page
