Sensepoint XCD RFD Technical Manual SPXCDHMRFENU Issue 1
9
4.3 Accessories
A range of accessories are available to allow use of Sensepoint XCD RFD in a wide
variety of applications. These include Pipe mounting bracket, Sunshade deluge cover,
Sensor collecting cone, Sensor flow Housing and Remote sensor mounting junction
boxes.
Standard Weather Protection
For UL/CSA Junction Box
(P/N: 2430-0021)
For Sensepoint / 705
(P/N: 02000-A-1640/1635)
For Sensepoint / 705
(P/N: 02000-A-1642)
The Standard Weather Protection is designed to
protect the sensor from changes in environmental
conditions. This is recommended to be tted to
a Sensepoint XCD sensor and Sensepint / 705
sensors.
Calibration Gas Flow Housing
The Calibration Gas Flow Housing (P/N: 02000-
A-1645) may be used for either calibration of the
Sensepoint / 705 sensor or if the Sensepoint /
705 sensor is to be used as part of a Aspirated
Sampling System.
Collecting Cone
Remote Sensor Mounting
Sensepoint Filter and Filter Housing
The Collecting Cone is an optional accessory that
may be tted to the Weather Protection of XCD
and Sensepoint / 705 sensors. The collecting
cone is designed for use with gases that are
lighter than air.
UL/CSA aluminum junction box, (P/N: 2430-0021)
is used for remote sensor mounting. Make
the connection from the junction box to the
transmitter using suitable cable and cable glands.
Sensepoint Stainless steel lter (P/N: 00780-
F-0018) and Filter Housing (P/N: 00780-C-
0038) is an optional accessory can be used to
offer additional protection to the Sinter in dry,
and dusty applications.
