4. Product Specification
4.2. SmartLine Wireless Transmitter User Environment
Revision 1 SmartLine Wireless Transmitter Professional Installation Guide 9
4.2 SmartLine Wireless Transmitter User Environment
Table 4-2 User Environment Specifications for SmartLine Wireless Transmitter
Item
Specification
Operating Temperature:
–40ºC to +85ºC (–40°F to +185°F)
Storage Temperature:
–40ºC to +85ºC (–40°F to +185°F)
Operating Humidity:
0 to 100% RH
Other Environmental specifications and information may be found in the appropriate Instrument
Specification available on the Honeywell website. www.honeywellprocess.com
4.3 SmartLine Wireless Instrument Power Specifications
The SmartLine Wireless Transmitters operate from two (2) D-size 3.6V Lithium Thionyl
Chloride (Li/SOCl2) batteries. These are joined in series to produce a maximum voltage of +7.6
Vdc. An optional external +24 Volt power supply option is also available.
4.4 Weight
Most non-pressure sensing versions of the SmartLine Wireless transmitter have a maximum
weight of 7.0 lbs (3.2 kg). Pressure transmitter versions can weigh from 7.0 lbs (3.2 kg) to 35 lbs
(15.9 kg) for a flange equipped model. These weights do not include remote cables or antennas.
Add 8.0 lbs (3.6 kg) to any transmitter equipped with the stainless steel housing option (A3 or
SH option).
