T7560A,B,C DIGITAL WALL MODULES
95-7620-4
EN1B-0146GE51 R0303
5
Configuration Items in Software Version 2.10
and Above
P6 Device type
This item configures different devices.
IMPORTANT:
Stay on P6:1 and do not change to other
configurations.
P7 Temperature offset
•
Temperature offset; values of 0 through 99 are
valid. 50 = no change, 49 = -0.1 Kelvin, 51 =
+0.1 Kelvin, etc. This offset varies the LCD display
value, only. It must be set separately in the XL10
controller.
P8 Switch back fan / temperature offset if unoccupied
• 01 --> enable FAN Key / enable Setpoint Key
• 02 --> enable FAN Key / disable Setpoint Key
• 03 --> disable FAN Key / enable Setpoint Key
• 04 --> disable FAN Key / disable Setpoint Key
To "disable" means to switch back to FAN= auto / Setpoint
offset = zero and disable operation.
To "enable" means to make normal operation possible (no
action if unoccupied).
"Unoccupied" means:
• Effective Unoccupied (moon on continuously)
or
• Override Unoccupied (moon flashing).
Works only with configuration P4:1: LCD signalling
Setpoint will be set to zero only if set to relative: P1:1 and
P1:3.
How to Check the Software Version
Press the left and right button for approx. 5 seconds: After a
LCD display test, you will see the current SW version of the
device.
