Honeywell T8611G Chronotherm IV Deluxe User Manual

T8611G CHRONOTHERM
®
IV DELUXE PROGRAMMABLE HEAT PUMP THERMOSTAT
68-0165—1
21
Refer to Table 14 for thermostat cross referencing information.
Table 14. Thermostat Cross Reference Information.
(continued)
Model
Number Description
TRADELINE®
Replacement Remarks
T8611G Two-stage heat and one-stage cool heat pump thermostat; powered direct from 24 Vac
transformer; automatic changeover; system switch—EM HEAT-HEAT-OFF-COOL-AUTO; fan
switch—ON-AUTO; O/B or O and B terminals
T8611G1004 TRADELINE® thermostat; Honeywell
logo.
T8611G2002 Configure changeover in Installer Setup 12
and O/B terminal in 29; jumper Y1 to W1.
T8611G1012 Canadian TRADELINE® thermostat;
Honeywell logo; degree C.
T8611G2002 Configure changeover in Installer Setup 12,
°C in 14 and O/B terminal in 29; jumper Y1
to W1.
T8611G1020 Heil Quaker; part no. HQ713669HW. T8611G2002 Configure changeover in Installer Setup 12
and O/B terminal in 29; jumper Y1 to W1.
T8611G1038 Trane; part no. THT-0603; ordering no.
X13510323-13-7.
T8611G2002 Configure changeover in Installer Setup 12
and O/B terminal in 29; jumper Y1 to W1.
T8611G1046 Carrier; part no. HH07AE001. T8611G2002 Configure changeover in Installer Setup 12
and O/B terminal to O in 29; jumper Y1
to W1.
T8611G1053 Lennox; part no. 27H3001. T8611G2002 Configure changeover in Installer Setup 12
and O/B terminal in 29; jumper Y1 to W1.
T8611G1095 Trol-A-Temp® by Honeywell thermostat. T8611G2051
a
O and B terminals are not used.
T8611G1103 TRADELINE® thermostat; Honeywell
logo; Premier White® color.
T8611G2002 Configure changeover in Installer Setup 12
and O/B terminal in 29; jumper Y1 to W1;
taupe color.
T8611G1111 Trane; Premier White® color;
part no. TAYSTAT501.
T8611G2002 Wiring differences (old=new): F=L, B=C;
configure changeover in Installer Setup 12
and O/B terminal to O in 29; taupe color.
T8611G1145 Canadian TRADELINE® thermostat;
Honeywell logo; Premier White® color;
degree C.
T8611G2002 Configure changeover in Installer Setup 12,
°C in 14 and O/B terminal in 29; jumper Y1
to W1; taupe color.
T8611G1152 Solitare logo; Premier White® color;
Nordyne part no. 9132410.
T8611G2002 Configure changeover in Installer Setup 12
and O/B terminal in 29; jumper Y1 to W1;
taupe color.
T8611G1178 Canadian Carrier; Premier White® color;
degree C; part no. HH07AE001C-W.
T8611G2002 Configure changeover in Installer Setup 12,
°C in 14 and O/B terminal in 29; jumper Y1
to W1; taupe color.
T8611R Two-stage heat and one-stage cool heat pump thermostat; powered direct from 24 Vac
transformer; system switch—EM HEAT-HEAT-OFF-COOL; fan switch—ON-AUTO;
O/B or O and B terminals
T8611R1000 TRADELINE® thermostat;
Honeywell logo.
T8611G2002 Configure O/B terminal in Installer
Setup 29; no P terminal.
T8611R1018 York; part no. 025-27655. T8611G2002 Wiring differences (old=new): B=C, H=B,
X=L; configure O/B terminal in Installer
Setup 29.
T8611R1034 Rheem; Honeywell logo; part no.
41-21594-05.
T8611G2002 Configure O/B terminal in Installer
Setup 29; no P terminal.
T8611R1042 Canadian TRADELINE® thermostat;
Honeywell logo; degree C.
T8611G2002 Configure O/B terminal in Installer Setup 29
and °C in 14; no P terminal; taupe color.
T8611R1059 Coleman; part no. 3600A381. T8611G2002 Configure O/B terminal in Installer
Setup 29; no P terminal.
a
Contact Trol-A-Temp
®
for thermostat.
