TB7300 SERIES COMMUNICATING FAN COIL THERMOSTATS
62-2018—05 22
Fig. 11. Thermostat dimensions in inches (mm)
Agency Approvals all models:
UL: UL 873 (US) and CSA C22.2 No. 24 (Canada), File E27734 with CCN XAPX (US) and XAPX7 (Canada)
Industry Canada: ICES-003 (Canada)
C-Tick: EN55022:2006, IEC 61326-1:2005
Agency Approvals all models
FCC: Compliant to CFR 47, Part 15, Subpart B, Class A (US)
CE: EMC Directive 89/336/EEC (Europe Union)
Agency Approvals wireless models
FCC: Compliant to: Part 15, Subpart C
This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this
device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
Agency Approvals BACnet models
BTL
IMPORTANT
All TB7300 series controls are for use as operating controls only and are not safety devices. These instru-
ments have undergone rigorous tests and verifications prior to shipment to ensure proper and reliable opera-
tion in the field. Whenever a control failure could lead to personal injury and/or loss of property, it becomes the
responsibility of the user/installer/electrical system designer to incorporate safety devices (such as relays, flow
switch, thermal protections, etc…) and/or alarm system to protect the entire system against such catastrophic
failures. Tampering of the devices or miss application of the device will void warranty.
5
(125)
3-2/5 (86)
1-3/20 (29)
M21304
°C
°F
