6.7.3 P222 front dimensions
M33513
R1
RELAY
ON
R2
RELAY
ON
A B
FLAME ON
AUTO/MAN STORE
NO
SET YES
AUTO/ON
FLASH
(RESET
REQ)
MANUAL
(HAND)
OFF
SELF
CHECK
GAIN SET RESET
R1
TRIP DELAY
R2
TRIP DELAY
4.25" (108 mm)
3-19/64" (84 mm)
7-3/16"
(182 mm)
6-23/32"
(171 mm)
6.7.4 P222 side dimensions
7-13/64"
(183 mm)
6-13/32" (163 mm)
M33514
Mounting
Bracket
Terminals
Front
Faceplate
Terminals
7 CERTIFICATION
7.1 CSA
Complies to: CSA 213-M1987, CSA 142-M1987
8 DISPOSAL
Devices with electronic components:
WEEE Directive 2012/19/EU – Waste Electrical and Elec-
tronic Equipment Directive
At the end of the product life (number of operating cycles
reached), dispose of the packaging and product in a correspond-
ing recycling centre. Do not dispose of the unit with the usual
domestic refuse. Do not burn the product.
On request, old units may be returned carriage paid to the manu-
facturer in accordance with the relevant waste legislation require-
ments.
