WARNING
Failure to align the slot in the downrod with the tab
on the mounting bracket could cause the fan to fall,
which could result in serious injury or death.
!
!
Slot
Tab
9
STANDARD OR ANGLE MOUNTING INSTRUCTIONS
13. Install the ball end of the downrod into the
mounting bracket opening. Align the slot in the ball
with the tab in the mounting bracket. If installed
correctly, the downrod should not rotate in the
mounting bracket (Fig. 13).
12. Remove the six motor screws from the top of the
motor assembly and keep for blade attachment
(Fig. 12).
Mounting
Bracket
Motor Screw
with Washer
Downrod
Ball
Fig. 13
Fig. 12
Motor Screw
with Washer
