EXCEL 500/600 - INSTALLATION INSTRUCTIONS
EN1R-1047GE51 R0913
30
Sensors and Transducers
Table 16. Sensors suitable for use with Excel 500/600 (external transducer not required)
sensor type range
characteristic in controller
(set using CARE)
AF20 Outside Air Temperature Sensor -20…+30° C
NTC
VF20A Strap-On Temperature Sensor 0…+110° C
KTF20 Boiler Temperature Sensor 0…+100° C
LF20 Duct Temperature Sensor -30…+100° C
AQS51 or C7110C1001 CO
2
Sensor 0...2000 ppm CO
2
0…10 V = 0..2000 ppm
C7110A1005 Air Quality (Mixed Gas) Sensor 0…100% 0…10 V = 0…100%
T7560C1006 Combined Room Temp. / Humidity Sensor
or H7012B1023 Room Humidity Sensor
6…40°C NTC
20...95% relative humidity 0..10 V = 0...100%
Table 17. Room Temperature Sensors suitable for use with Excel 500/600 (external transducer not required)
sensor type range
characteristic in controlle
r
(set using CARE)
T7460A1001 Room Temperature Sensor
6...40°C NTC
T7460B1009 Room Temperature Sensor
setpoint wheel linear input
TF22 Room Temperature Sensor
6…40°C NTC
setpoint wheel linear input
operating knob -
T7460C1007 Room Temperature Sensor
6...40°C NTC
setpoint wheel linear input
occupancy button* -
T7460E1002 Room Temperature Sensor
6...40°C NTC
setpoint wheel linear input
occupancy button*
-
fan speed, 3 stages
T7460F1000 Room Temperature Sensor
6...40°C NTC
setpoint wheel linear input
occupancy button*
-
fan speed, 5 stages
T7460A1000 Room Temperature Sensor
6...40°C NTC
setpoint wheel linear input
occupancy button*
-
fan speed, 5 stages
T7460C1006 Combined Room Temperature / Humidity
Sensor
6…40°C NTC
20...95% r.h. 0..10 V = 0…100%
C7110D1009 Combined Room Temperature / Humidity
Sensor
6..40°C NTC
0...2000 ppm CO
2
0..10 V = 0…2000 ppm
setpoint wheel linear input
occupancy button* -
T7560B1008 Combined Room Temperature / Humidity
Sensor
6...40°C NTC
20...95% r.h. 0...10 V = 0...100%
setpoint wheel linear input
occupancy button*
-
fan speed, 5 stages
*supported in AH03
Table 18. Humidity Sensor suitable for use with Excel 500/600 (external transducer not required)
sensor type
characteristic in controlle
r
(set using CARE)
additional remarks
H7015B1020 Duct Humidity Sensor
0..10 V = 0...100% set jumper to 0...10 V
H7508A1042 Outside Humidity Sensor
