Remove telescoping
handle/wand
Position handle
Position tools
The telescoping handle/wand
(C) needs to be positioned and
secured in place. Align the telescop-
ing handle/wand with the recesses on
the upper handle. Push the wand all
the way down into the cup (D) until
the handle/wand release latches (E)
snap into position.
To remove the telescoping
handle/wand for tool use,
push down either release latch (E)
and pull upwards to remove.
4
3
05
(Cont’d) →
Stretch hose and guide into hose
clip. Align button on hose end (F)
with hole on hose connector (G). Slide
hose end over connector until the but-
ton “pops up” into place. To remove
hose from hose connector, press button
and pull hose end to release.
The hose connector swivels 360° for
convenience.
The powered pet hair cleaning
tool (H) is stored on the front of
the cleaner. Place bottom of tool into
recessed area first, pivot tool up and
snap in place.
5
6
E
E
F
H
G
C
D
E
E
K
I
J
Snap crevice tool (I), dusting brush
(J) and furniture nozzle (K) into
storage areas on back of cleaner.
7
Attach hose
