Problem Possible Cause Solution
Control surface does not
move
Control surface, control horn, linkage or servo
damage
Replace or repair damaged parts and adjust controls
Wire damaged or connections loose
Do a check of wires and connections, connect or
replace as needed
Transmitter is not bound correctly or the incorrect model was selected Re-bind or select correct model in transmitter
Flight battery charge is low Fully recharge ight battery
BEC (Battery Elimination Circuit) of the ESC is
damaged
Replace ESC
Controls reversed
Transmitter settings are reversed
Perform the Control Direction Test and adjust the
controls on transmitter appropriately
Motor power pulses then
motor loses power
ESC uses default soft Low Voltage Cutoff (LVC)
Recharge ight battery or replace battery that is no
longer performing
Weather conditions might be too cold Postpone flight until weather is warmer
Battery is old, worn out, or damaged Replace battery
Battery C rating might be too low Use recommended battery
Aircraft control surfaces do
not move after switch is
turned on
Aircraft was moving during initialization Keep aircraft still during initialization
Plastic Parts and Pushrods HBZ6109
Replacement Parts Optional Parts
Part # Description
HBZ6101 Hatch: Apprentice STOL 700mm
HBZ6102 Fuselage w/tail: Apprentice STOL 700mm
HBZ6103 Wing Set: Apprentice STOL 700mm
HBZ6104 Wing Bolts: Apprentice STOL 700mm
HBZ6105 Prop 6 x 3.5: Apprentice STOL 700mm
HBZ6106 Spinner w/Screw: Apprentice STOL 700mm
HBZ6107 Motor Collet: Apprentice STOL 700mm
HBZ6108 Motor Mount: Apprentice STOL 700mm
HBZ6109 Hardware Set: Apprentice STOL 700mm
HBZ6110 Landing Gear Set: Apprentice STOL 700mm
HBZ6111 Screw Set: Apprentice STOL 700mm
HBZ6112 Decal Sheet, Apprentice STOL 700mm
SPMXAM2900 Brushless Outrunner Motor: 1810-2000Kv 12-Pole
SPMSA203 2.2g Linear Servo High-Torque w/servo mount
SPMAS6420AA DSMX/SLT 6-Channel Rx AS3X/SAFE: Apprentice STOL
SPMR1275 SLT6LP 6-Channel Transmitter
SPMXAE06 Avian 6-Amp Smart Lite Brushless ESC; 2S-3S JST-PH
SPMXC0020 2S USB-C PH2.0 3-pin Charger
SPMA2002 Y-Harness: Ultra Micro 3"
SPMX3002S30 300mAh 2S 7.4v 30C LiPo; JST 2.0 PH 3-Pin
Part # Description
RFL1201 RealFlight 9.5 Software Only
RFL1203 RealFlight 9.5 Digital Download
RFL1205D RealFlight Trainer Edition Steam download
SPMWS2000 Wireless Simulator USB Dongle
SPMXCA326 Adapter: IC3 Battery / 2S UMX D
SPMR6775 NX6 6 Ch Transmitter Only
SPMXC1070 S150 AC/DC Smart Charger, 1x50W
SPMXC2050 S155 G2 1x55W AC Smart Charger
Part Description Quantity
Pushrods Two ailerons, elevator, rudder 4
Pushrod guides Elevator, rudder guides for fuselage 2
Control horns Two aileron, elevator, rudder 4
Servo covers Covers for aileron servos 2
Location Description Quantity
Propeller and spinner 2x6mm Self tapping 1
Motor mount M2x10 Machine screw 1
Propeller adapter M1.6x4 Machine screw 3
Wing to fuselage M2x12 Machine screw (thumb screw) 2
Servo retainer 1x3mm Self tapping 8
Hardware Screw Set HBZ6111
