Apprentice
®
STOL S 700mm
EN
3
Table of Contents
Aircraft Components ....................................................................................... 4
Aircraft Assembly ............................................................................................ 5
Install the Transmitter Batteries ....................................................................... 7
Transmitter Switches and LEDs ....................................................................... 7
Turning the Transmitter ON and OFF ................................................................ 8
Charge the Aircraft Battery .............................................................................. 8
Installing the Flight Battery and Arming Electronic Speed Control (ESC) ........... 9
Center of Gravity (CG) ................................................................................... 10
Control Direction Test ................................................................................... 11
Before Your First Flight .................................................................................. 11
Choose a Flying Field .................................................................................... 12
Range Test .................................................................................................... 12
Flight Control ................................................................................................ 13
Sensor Assisted Flight Envelope (SAFE) Technology ....................................... 14
Preight Checklist ......................................................................................... 16
Flying ........................................................................................................... 16
Trimming the Aircraft .................................................................................... 18
Control Surface Centering ............................................................................ 18
Post Flight..................................................................................................... 19
Transmitter and Receiver Binding .................................................................. 19
Bind and Fly Transmitter Setup ..................................................................... 20
Service and Repairs ...................................................................................... 21
Trouble Shooting Guide for SAFE Technology ................................................. 23
Trouble Shooting Guide ................................................................................. 23
Replacement Parts ........................................................................................ 24
Optional Parts ............................................................................................... 24
Plastic Parts and Pushrods HBZ6109 ........................................................... 24
Hardware Screw Set HBZ6111 ...................................................................... 24
Glossary of Important Terms ......................................................................... 25
AMA National Model Aircraft Safety Code ...................................................... 25
Limited Warranty .......................................................................................... 26
Contact Information ...................................................................................... 27
FCC Information ............................................................................................ 27
IC Information ............................................................................................... 27
Compliance Information for the European Union ............................................ 28
Registration
Register your product today to join our mailing list
and keep up to date with product updates, offers and
HobbyZone
®
news.
Completion Guide
Scan the QR code to go to the product completion
guide for information on other compatible batteries
and chargers.
* The weight provided is for the aircraft and ight control components.
No additional payload is allowed. MTOM is weight with recommended battery.
Specifications
Wingspan 27.6" (700mm)
Length 19.29" (490mm)
Weight*
Without Battery: 4.9oz (140g)
With Recommended 2S 300mAh Flight Battery: 5.5oz (157g)
HBZ6150
Included Equipment
Receiver
Spektrum
™
AS6420A 6 Channel AS3X & SAFE Dual Protocol
UMX receiver (SPMAS6420A)
ESC Avian 6-Amp Smart Lite (SPMXAE06)
Motor 1810-2000Kv 12-Pole (SPMXAM2900)
Propeller 6 x 3.5 (HBZ6105)
Servos
(2) Aileron, 2.2g High Torque Linear Servo (SPMSA203)
(1) Elevator, 2.2g High Torque Linear Servo (SPMSA203)
(1) Rudder, 2.2g High Torque Linear Servo (SPMSA203)
RTF Included Equipment
Flight Battery
300mAh 2S 7.4v 30C LiPo; JST-PH 2.0 3-Pin
(SPMX3002S30)
Battery Charger 2S LiPo USB-C Charger (SPMXC0020)
Transmitter Spektrum
™
SLT6LP 2.4GHz (SPMR1275)
Transmitter Batteries 4 AA Alkaline
RTF Required Equipment
Power Supply USB-C power supply and charge cable
BNF Required Equipment
Flight Battery 300mAh 2S 7.4v LiPo; JST-PH 2.0 3-Pin
Battery Charger 2S LiPo Charger
Transmitter Spektrum
™
DSMX Transmitter
Optional Accessories
SPMR6775 NX6 6 Ch Transmitter Only
RFL1205D RealFlight Trainer Edition Steam download
SPMWS2000 WS2000 Wireless Simulator USB Dongle
SPMXC2050 Smart S155 AC Charger, 1x55W
SPMXCA326 Adapter: IC3 Battery / JST-PH Device
