EN
Control Horn and Servo Arm Settings
The table to the right shows the factory settings for the control horns and servo
arms. Fly the aircraft at factory settings before making changes.
NOTICE: If control throws are changed from the factory settings, the AR636
gain values may need to be adjusted. Refer to the Spektrum AR636 manual for
adjustment of gain values.
After flying, you may choose to adjust the linkage positions for the desired
control response. See the table to the right.
Horns Arms
Elevator
More control throw Less control throw
SAFE
®
Select Switch Designation
SAFE
®
Select technology can be easily assigned to any open switch on
your transmitter. With this new feature, you now have the flexibility to enable or
disable the technology while in flight.
IMPORTANT: Before assigning your desired switch, ensure that the travel for
that channel is set at 100%.
Assigning a switch
1. Bind the aircraft correctly to activate SAFE Select to allow the system to be
assigned to a switch.
2. Hold both transmitter sticks to the inside bottom corners and toggle the
desired switch 5 times to assign that switch. The control surfaces of the
aircraft will move, indicating the switch has been selected.
Repeat the process to assign a different switch if desired.
1 3
2 4
5
Mode 1 and 2 Transmitters
