HORNER XLE 5 Manual

Page 2
TECHNICAL SPECIFICATIONS
General Specifications
Primary Power Range 10-30VDC
Max. Current
500mA, Class 2
750mA, Class 2 with heater*
Required Power
(Steady State)
130mA @ 24VDC
Inrush Current 30A for < 1ms
Typical power back-
light 100%
136mA @ 10V (1.36 W)
64mA @ 24V (1.53 W)
Power Backlight Off 15mA @ 24V (0.36 W)
Power Ethernet
Models
35mA @ 10V (0.35 W)
20mA @ 24V (0.48 W)
Heater Option* 250mA @ 24VDC with heater*
Real Time Clock
Battery backed; lithium coin cell
CR2450
Clock Accuracy +/- 90 Secs/Month
Relative Humidity 5 to 95% Non-condensing
Operating Temp. -10°C to +60°C
Storage Temp. -20°C to +70°C
Weight 0.75 lbs/ 340 g (without I/O)
Altitude Up to 2000m
Rated Pollution
Degree
Evaluated for Pollution Degree 2
Rating
Certifications (UL/CE) North America or Europe
Enclosure Type 1, 3R, 4, 4X, 12, 12K & 13
*Heater Option (Model # plus "-22")
Control and Logic
Control Lang.
Support
Register-Based Advanced Lad-
der;
Variable-Based Advanced Lad-
der;
IEC 61131-3 Languages
Logic Program Size 256kB
Scan Rate
0.7ms/kB logic (XLE)
0.8ms/kB logic (XLT)
Digital Inputs 2048
Digital Outputs 2048
Analog Inputs 512
Analog Outputs 512
Gen. Purpose
Registers
9,999 (words) Retentive
2,048 (bits) Retentive
2,048 (bits) Non-retentive
User Interface
Display Type
Transflective LCD Sun- light
Readable
Resolution
128 x 64 pixels (XLEe)
160 x 128 pixels (XLTe)
Color Monochrome
Built-In Storage 16 MB
User-Program.
Screens
1023 max pages;
50 objects per page
Backlight LED
Backlight Lifetime 30,000+ hrs
Brightness Control
0-100% (XLT)
On/Off (XLE) via
System Register %SR57
Number of Keys
20 (XLE)
5 (XLT)
Touchscreen (XLTe) Resistive 1,000,000+ touch life
Connectivity
Serial Ports
RS-232 full handshaking or RS-
485 half duplex on first Modular
Jack (MJ1)
RS-232 or RS-485 on second
Modular Jack (MJ2)
USB Mini-B Programming only
CAN 1 x CAN Port, Isolated 1 kV
CAN
Protocols
CsCAN, CANopen, DeviceNet,
J1939
Ethernet
Ethernet versions only
(XLEe &XLTe)
Ethernet
Protocols
TCP/IP, Modbus TCP, FTP,
SRTP, EGD, ICMP, ASCII
Remote I/O
SmartRail, SmartStix,
SmartBlock, SmartMod
Removable Memory
MicroSD, SDHC, SDXC, IN
FAT32 format, support for 32 GB
max. Application Updates,
Datalogging
Audio
(XLTe only)
Beeper, System or
Software Controlled
