HORNER XLE 5 Manual

Wiring:Model 5
Page 4
Model 5 Technical Specifications
Digital DC Input
Inputs per Module
12 Including 4 Configurable HSC
Inputs
Commons per Module 1
Input Voltage Range 12VDC / 24VDC
Absolute Max. Voltage 30VDC Max.
Input Impedance 10kΩ
Input Current Positive Logic Negative Logic
Upper Threshold
Lower Threshold
0.8mA
0.3mA
-1.6mA
-2.1mA
Max. Upper Threshold 8VDC
Min. Lower Threshold 3VDC
OFF to ON Response 1ms
ON to OFF Response 1ms
High Speed Counter
Max Freq
500kHz
Digital DC Outputs
Outputs per Module
16 Including 2 Configurable PWM
Outputs
Commons per Module 1
Output Type Sourcing / 10kΩ Pull-Down
Output Frequency 500kHz
Absolute Max. Voltage 28VDC Max.
Output Protection Short Circuit
Max. Output Current /
Point
0.5A
Max. Total Current 4A Continuous
Max. Output Supply
Voltage
30VDC
Min. Output Supply
Voltage
10VDC
Max. Voltage Drop at
Rated Current
0.25VDC
Max. Inrush Current 650mA per Channel
Min. Load None
OFF to ON Response 1ms
ON to OFF Response 1ms
Output Characteristics Current Sourcing (Pos. Logic)
PWM Out ≈ 5kHz
Rise Time 50 - 115μs
Fall Time 8-20μs
