Upkeep & Clean-up of the Freestyle
3
Cleaning & Rotating Brushes
Clean and rotate brushes each time you clean out the Freestyle. The brush bristles
acquire a “set” in the direction they revolve unless switched regularly.
Unplug machine from power.
Remove the Velcro skirt.
Press spring lock to release brush
guard/end cover.
Pull back on clip; lift out brushes.
Remove brushes and clean out
underside of machine.
Switch brushes to opposite drive
shafts. Brushes fit down over
shaft and engage on 3 pins near
bottom of shaft. Be sure brush
clip snaps into position.
Insert hinged bar of brush guard/end cover into
lower slot. Push all the way up, depress lock
button and slip brush guard into place.
Freestyle brushes can also be switched end-to-
end if desired. Remove screw holding brush clip
in place, reassemble at other end of brush and
replace.
a
g
h
b
d
e
f
c
Cleaning the Vacuum Shoe
& Brush Guard
Remove lint and fuzz from the
vacuum shoe and brush guard.
4
Cleaning the Motor Vents & Filter
Remove the vacuum hose from machine base and
vacuum motor vents after each use.
5
Vacuum shoe
Brush guard
