Host Liberator - Upkeep & Clean-up (Reliant)

26
Upkeep & Clean-up of the Reliant
2
Cleaning & Rotating Brushes
Clean and rotate the brushes each time you clean the Reliant. The brush bristles acquire
a “set” in the direction they revolve unless switched regularly.
Unplug machine from power.
Press spring lock to release brush
guard/end cover.
Pull back on clip; lift out brushes.
Remove brushes and clean out
underside of machine.
Switch brushes to opposite drive
shafts. Brushes fit down over shaft
and engage on 3 pins near bottom
of shaft. Be sure brush clip snaps
into position.
Insert hinged bar of brush guard/end cover
into lower slot. Push all the way up, depress
lock button and slip brush guard into place.
Reliant brushes can also be switched end-to-
end if desired. Remove screw holding brush
clip in place, reassemble at other end of brush
and replace.
a
f
g
b
d
e
c
Cleaning the Motor Vents
Vacuum the motor vents after each use.
1
M
otor vents
